Cylindrical swing turnstile
  • Cylindrical swing turnstileCylindrical swing turnstile
  • Cylindrical swing turnstileCylindrical swing turnstile
  • Cylindrical swing turnstileCylindrical swing turnstile

Cylindrical swing turnstile

ZOJE-B507® cylindrical swing turnstile is vertical type, occupying much fewer space than traditional ones.One set can form a channel and the width of channel can reach 1 meter.Cylindrical swing turnstile gate usually used for disabled channel and small cart channels.It is a good choice to use ZOJE-B507 cylindrical swing gate turnstile in the place where the installation space is limited.

Send Inquiry    PDF DownLoad

Product Description

Cylindrical swing turnstile

Cylindrical swing gate turnstile ZOJE-B507® standard diameter is 168mm, which can be customized according to specific project needs. Also, it can be made into different colors by painting.
As usual, this swing turnstile can work as single way or bidirectional passage.
Customers can choose 316 instead of the standard 304 stainless steel for longer lifespan serving in severe circumstances.
Despite its tiny and slim presentation, you definitely can integrate other access control modules to make the best entrance security management solution, including biological recognition algorithms such as face or fingerprint recognition technology, traditional ID / IC / RFID card reader, also bar code and QR code reader, etc.
Customers can customize this model as they need. ZOJE is definitely your reliable choice for customized turnstile gates.


Product Parameter (Specification)


Standard Optional
Turnstile Type Cylindrical swing gate turnstile -
Dimension Φ168/Φ129/Φ89*1000mm Customized
Material 304 Stainless Steel 316 Stainless Steel
Channel Width 600mm 900mm /Customized
Door Material Acrylic Tempered glass
Drive Type Brush motor Brushless/Servo motor
Unlock time 0.2S -
Direction Single / Bidirectional -
Power Supply AC110-230,50/60Hz -
Operation Voltage DC24V,3A -
Function Fail safe, anti-clamping,anti-pinch -
Working environment Indoor & outdoor -
Working Temperature -70 C -15 C -
Relative Humidity Less Than 95%, No Condensation -
Pass Speed 35 person/Minute -
Input Interface Dry contact/Relay Signal -
Communication Interface RS485/TCPIP -
LED Indicator Yes -
Emergency Open Automatic -
Waterproof IP67 -
Access Control Can be integrated with any kind of access control system. -

Product Feature And Application

ZOJE-B507 Cylindrical swing gate turnstile
●Unique technology: Self-developed mechanical structure together with powerful motor enables the turnstile running smoothly and stably in the long run.
●Flexible and compact cabinet , can meet different installation spaces
●The Equipment Has A Device And Circuit Testing Function, Easy Maintenance
●Equipment With Traffic Indicator
●Equipment With Automatic Protection, Automatic Reset
●Unified standard external electrical interface, which can be connected with various reading and writing devices(ID Card / IC Card /EMcard / Fingerprint Face Recognition / QR Code / ESD system)
●ZOJE-B507 cylindrical swing gate turnstile widely used in office building,hospital and other places, and can be easily integrated with your existing control software.
